The equipment is widely used in the production of iron parts, dumbbell, luggage wheel, gel, skid pad and other polyurethane products.

Medium temperature elastomer equipment is a new product independently developed by linxin company, which has the characteristics of high repeat injection accuracy, even mixing, stable performance, simple operation and high production efficiency.

Main technical parameters of the equipment：

Head: high performance mixing device, adjustable pressure, material spit out accurate synchronization, even mixing; Brand - new mechanical seal structure, ensure non - discharge.

Metering pump, motor: high temperature and low speed high-precision metering pump, accurate metering, accuracy error no more than ±0.5%; By frequency converter and motor to adjust raw material flow and pressure, high precision, simple and quick proportional adjustment

Vacuum pump: rotary vane high performance vacuum pump, fast pumping speed, quiet.

Control system: PLC and touch screen human-machine interface are adopted to control pouring, automatic cleaning and air flushing of equipment, with stable performance and strong operability. When abnormal conditions occur, it will automatically discriminate, diagnose and alarm, and display abnormal factors. Can load remote control, forget cleaning function, automatic cleaning and feeding power failure and other additional functions.

Vacuum and mixing system: high efficient vacuum defrosting device, combined with special mixing head, to ensure no bubbles in products.
